100% USA Origin

AGR  Vietnam

Code: C522
The Light Polarizer is a viewing device for detecting material flows and stresses in PET and PEN preforms.
Features:
Ability to view images in full color 185x400mm (7.25-15.75in) polarizing field with light source Illuminator with 15W fluorescent light source with integrated on/off switch
Table-mounted unit with adjustable viewing angle
Reference poster for identification of preform defects included

100% USA Origin

AGR  Vietnam

Code: CRATE-LP
LIGHT POLARIZER PACKING CHARGE

100% USA Origin

AGR  Vietnam

Code: C520
The Manual Preform Thickness Gauge is a manually operated measuring device.
Features:
- Necessary adjustable mechanical fixturing to accommodate\
different preform sizes and shapes
- Dial gauge with digital readout, resolution 0.001mm
Note: THE ABOVE ITEM INCLUDES THE FOLLOWING:
Serial Cable

100% USA Origin

AGR  Vietnam

Code: CRATE-MPTG
MPTG PACKAGING CHARGE

100% USA Origin

AGR  Vietnam

Code: C526
The Manual Preform Perpendicularity Gauge is a manually operated measuring device.
Features:
- Necessary adjustable mechanical fixturing to accommodate
different sizes and shapes
- Neck adapters for 28mm and 38mm PCO finishes
- Dial gauge with digital readout, resolution to 0.001mm
Note:THE ABOVE ITEM INCLUDES THE FOLLOWING:
RS232 Cable Included.

100% USA Origin

AGR  Vietnam

Code: CRATE-MPPG
MANUAL PREFORM PERP GAUGE PACKAGING

100% USA Origin

AGR  Vietnam

Code: 6526002
MAGNIFYING GLASS, W/LIGHT

100% USA Origin

AGR  Vietnam

Code: C193
HHTP-2000

The Hand Held Thickness Probe is a battery-powered portable thickness measuring instrument providing a quick, accurate
method of measuring the thickness of non-conductive materials.
Features:
- Measures thickness up to 5mm
- English / Metric operation
- Operator calibration for multiple materials
- RS232 output
- Data storage for thickness, date, and time
- Uses rechargeable and user-replaceable battery
Includes AC converter/battery charging unit, rugged storage case, and thickness probe target

100% USA Origin

AGR  Vietnam

Code: 8193202
BATTERY PACK ASSEMBLY

100% USA Origin

AGR  Vietnam

Code: CRATE-HHTP2
THICKNESS PROBE PACKING CHARGE

100% USA Origin

AGR  Vietnam

Code: C225
GAWIS 4D
GAWIS 4D is a comprehensive, automated measuring system for plastic bottles, containers and preforms. The Gawis 4D
system provides fast, accurate, non destructive measurement of thickness and dimensional attributes.
Dimensional measurements: Body, Base clearance, Finish
Thickness and Material distribution on Neck, Shoulder, Sidewall, Heel with Vertical scan (providing distribution map of the
vertical sidewall) and with Horizontal scan (providing a map of material distribution around circumference of the sample)
Features*
- Large touch panel user interface with configurable display and touch/drag operation (live measurements data, Vision
image, thickness graphs, job set ups, logs, statistics and diagonostics, historical data.
- Precision dimensional measurement – utilizing telecentric optics and lighting in combination with high pixel density
cameras
- Thickness measurement utilizing IR based technologies
- Industry 4.0 standard communication protocols
- Universal centering device for precise sample positioning
- Powerful, easy-to-use system software
- Removable light-tube permits dimensional measurement of filled and closed containers
- Automatic base clearance measurement
- Autojob = simplified job set up by providing automated recognition of key finish measurements on samples.
Includes:
1 plate assembly for bottles
1 plate assembly for preforms
THE ABOVE ITEM INCLUDES THE FOLLOWING:
Thickness Inspection
Vision Inspection
UI Display, English Language
Power Cord, North and South America
240V Input Power Option
Total Care Program support not included
Preform Centering Cup diameter of 23.57MM
Preform Holder Centering Pin Length of 55MM







100% USA Origin

AGR  Vietnam

Code: CRATE-GAWIS4D
GAWIS 4D PACKING CHARGE

100% USA Origin

AGR  Vietnam

Code: K225001-CONFIG
KIT, GAWIS 4D REC SPARE PARTS
